VDS Fire Rated Swing Doors

The most versatile solution for applications demanding EI class protection

VDS Fire Rated Swing Doors are fire rated glass doors tested for the highest standard of protection and safety. They can be latched or unlatched glazed doors, with fittings and accessories for both single and double doors. The exceptional user-friendliness of the VDS System renders it the optimal choice. VDS Swing Doors seamlessly integrate into the VDS Framing System, offering expansive glass panels for enhanced visibility and aesthetic appeal. The modular system is delivered to the construction site fully assembled, necessitating minimal on-site assembly.

Attributes & Benefits
Performances
Customization
Applications
Showcases

Attributes & Benefits

Fire-rated

Radiant Heat

CE marked

Impact resistance

Made in India

Bi-directional fire protection for 120+ minutes
Blocks heat radiation and provides insulation (20 minutes)
Available in single and double glazing
Swiss reliability & precision with unmatched aesthetics
Up to Class 4 Air Permeability tested and certified as per EN 12207 & EN 1026
Up to Class 3 Wind Resistance tested and certified as per EN 12210 & EN 12211
Sustains repeated opening & closing of 200000 cycles as per EN 12400
Glass has impact resistance of level 1(B)1
Glass has extended exposure time of 5,000 hours UV stability versus standard 2,000 hours (EN ISO 12543-4)
Excellent acoustic insulation properties with hardware options
Fire-resistant system tested and certified as per stringent international standards
Manufactured in a state-of-the-art fabrication facility that is 3rd party audited & certified
Glass used is EPD certified
The entire system is Greenpro certified
Manufactured locally for fast deliveries
On site assistance and installation by a network of VDS Certified Installers, who are trained and certified by Vetrotech

Customisable Fire-Rated Swing Doors with Heavy Duty Hardware

VDS fire-rated swing doors can be customised to support heavy-duty hardware to meet specific project requirements, accommodating a total lock depth of 150 mm. Specially designed wider frames allow easy integration with advanced locking systems like self monitored motorized locks, access control solutions, and panic hardware—ensuring safety and durability in fire-rated conditions.

Ideal for hospitals, educational institutions, commercial buildings, and other high-footfall environments, these doors seamlessly support features like panic bars, door closers, card readers, and most access control systems.

Performances

With outstanding safety and performance in one package, the VDS System offers the highest level of fire resistance available today. For use as fire barriers in hallways, stairwells and areas of high risk like server rooms and vaults. VDS Swing Doors are available in fire ratings ranging from 20 minutes to 2 hours. VDS Systems are tested in accordance with EN standards, British standards, and other international standards. The products are CE marked and audited by TUV and UL.

Customization

All characteristics described above are examples. All our products and systems can be customised to meet your specific needs. Vetrotech provides design-assist support that ensures your project meets your requirements and design goals.
Together, let’s make your project unique!

Learn more

Applications

Doors

VDS Fire Rated Swing Doors find application in all building segments including but not limited to commercial, educational, residential, industrial, hospitality, health care, public and assembly buildings. They can be used in:

Main entrance, lift lobbies and basement car parks
Internal and external fire exits accompanied by panic hardware
Openings of compartmentation walls
Doors leading to refuge area
Metro stations, malls, airports
Commercial centres and offices
Machine rooms
Others areas of high risk

Fire testing video

VDS Doors are tested along with Vetrotech fire rated glass, such as CONTRAFLAM.

Curious to see how CONTRAFLAM glass reacts in case of a fire? Discover this video showcasing its fire test.
